COMP Cams Valve Lock 11/32in Single Groove

lock angle and 11/32" valve stem size is a perfect replacement lock for stock engine rebuilds. It is recommended only for street Applications with lighter valve spring loads. It is critically important to make sure valve locks match the valve size. There should always be a small gap between the two halves of the lock when they are properly positioned on the valve stem. If the two halves fit together without a gap, they are too large. If the locks fit tight to the stem and leave a gap between the middle of the lock and the OD of the stem, the locks are too small. Most people believe that the tang inside a valve lock Oldsmobile the retainer and valve spring in place while the engine is running. This is not the case. The cross-section of material in the tang is not strong enough to withstand open spring loads of 1000 lbs. or more. The sole purpose of the tang is to temporarily locate the lock, retainer and spring relative to the valve until the taper of the retainer can nest around the outside surface of the lock. This creates a "collet" effect that binds the two together. The more spring force exerted on the retainer (as the valve opens), the more force applied by the "collet" effect to keep the retainer and lock in place.

This Part Fits:

Year	Make	Model	Submodel
1980-1981	Buick	Century	Base
1982-1985	Buick	Century	Custom
1980-1981,1984	Buick	Century	Estate
1985	Buick	Century	Estate Wagon
1980-1985	Buick	Century	Limited
1984	Buick	Century	Olympia Limited
1980-1981	Buick	Century	Sport
1983-1984	Buick	Century	T-Type
1980-1987	Buick	Electra	Estate Wagon
1980-1985	Buick	Electra	Limited
1980-1984	Buick	Electra	Park Avenue
1980-1983	Buick	Estate Wagon	Base
1980-1981	Buick	LeSabre	Base
1985	Buick	LeSabre	Collector's Edition
1982-1986	Buick	LeSabre	Custom
1985-1990	Buick	LeSabre	Estate Wagon
1980-1986	Buick	LeSabre	Limited
1982	Buick	LeSabre	Limited Edition F/E
1981	Buick	LeSabre	Sport
1980-1981,1986-1987	Buick	Regal	Base
1987	Buick	Regal	GNX
1984-1987	Buick	Regal	Grand National
1980-1981,1986-1987	Buick	Regal	Limited
1984-1986	Buick	Regal	T-Type
1980-1985	Buick	Riviera	Base
1982	Buick	Riviera	Limited Edition
1983-1985	Buick	Riviera	Luxury
1980	Buick	Riviera	S
1981	Buick	Riviera	T-Type
1983	Buick	Riviera	XX Anniversary Edition
1980-1981	Buick	Skylark	Base
1986-1988	Buick	Skylark	Custom
1980-1981,1986-1988	Buick	Skylark	Limited
1980-1981	Buick	Skylark	Sport
1986-1987	Buick	Somerset	Custom
1986-1987	Buick	Somerset	Limited
1986	Buick	Somerset	T-Type
1985	Buick	Somerset Regal	Base
1985	Buick	Somerset Regal	Limited
1987-1990	Cadillac	Brougham	Base
1987-1990	Cadillac	Brougham	d'Elegance
1986	Cadillac	Fleetwood	Brougham
1986	Cadillac	Fleetwood	Brougham d'Elegance
1985-1986	Chevrolet	Astro	Base
1985-1986	Chevrolet	Astro	CL
1985-1986	Chevrolet	Astro	CS
1987-1989	Chevrolet	Beretta	Base
1989	Chevrolet	Beretta	GT
1994	Chevrolet	Blazer	Base
1992-1993	Chevrolet	Blazer	Cheyenne
1987	Chevrolet	Blazer	Custom Deluxe
1988-1991	Chevrolet	Blazer	Scottsdale
1987-1994	Chevrolet	Blazer	Silverado
1994	Chevrolet	Blazer	Silverado Sport
1980	Chevrolet	C10	Big Ten
1980-1981	Chevrolet	C10	Cheyenne
1981-1986	Chevrolet	C10	Custom
1980	Chevrolet	C10	Custom Deluxe
1981	Chevrolet	C10	Deluxe
1980-1986	Chevrolet	C10	Scottsdale
1980-1986	Chevrolet	C10	Silverado
1981-1986	Chevrolet	C10 Suburban	Custom
1980	Chevrolet	C10 Suburban	Custom Deluxe
1981	Chevrolet	C10 Suburban	Deluxe
1980,1982,1984-1986	Chevrolet	C10 Suburban	Scottsdale
1980,1982-1986	Chevrolet	C10 Suburban	Silverado
1994-1995	Chevrolet	C1500	Base
1988-1995	Chevrolet	C1500	Cheyenne
1988-1992	Chevrolet	C1500	Scottsdale
1988-1995	Chevrolet	C1500	Silverado
1990-1995	Chevrolet	C1500	WT
1992-1995	Chevrolet	C1500 Suburban	Base
1995	Chevrolet	C1500 Suburban	LS
1995	Chevrolet	C1500 Suburban	LT
1992-1994	Chevrolet	C1500 Suburban	Silverado
1980-1981	Chevrolet	C20	Cheyenne
1981-1986	Chevrolet	C20	Custom
1980	Chevrolet	C20	Custom Deluxe
1981	Chevrolet	C20	Deluxe
1980-1986	Chevrolet	C20	Scottsdale
1980-1986	Chevrolet	C20	Silverado
1981-1986	Chevrolet	C20 Suburban	Custom
1980	Chevrolet	C20 Suburban	Custom Deluxe
1981	Chevrolet	C20 Suburban	Deluxe
1980,1982,1984-1986	Chevrolet	C20 Suburban	Scottsdale
1980,1982-1986	Chevrolet	C20 Suburban	Silverado
1994-1995	Chevrolet	C2500	Base
1988-1995	Chevrolet	C2500	Cheyenne
1988-1992	Chevrolet	C2500	Scottsdale
1988-1995	Chevrolet	C2500	Silverado
1994-1995	Chevrolet	C2500	WT
1992-1995	Chevrolet	C2500 Suburban	Base
1995	Chevrolet	C2500 Suburban	LS
1995	Chevrolet	C2500 Suburban	LT
1992-1994	Chevrolet	C2500 Suburban	Silverado
1980-1981	Chevrolet	C30	Cheyenne
1981-1986	Chevrolet	C30	Custom
1980	Chevrolet	C30	Custom Deluxe
1981	Chevrolet	C30	Deluxe
1980-1986	Chevrolet	C30	Scottsdale
1980-1986	Chevrolet	C30	Silverado
1994-1995	Chevrolet	C3500	Base
1988-1995	Chevrolet	C3500	Cheyenne
1988-1992	Chevrolet	C3500	Scottsdale
1988-1995	Chevrolet	C3500	Silverado
1980,1988,1993-1994	Chevrolet	Camaro	Base
1980-1986	Chevrolet	Camaro	Berlinetta
1985-1990	Chevrolet	Camaro	Iroc-Z
1987	Chevrolet	Camaro	LT
1980	Chevrolet	Camaro	Rally Sport
1989-1992	Chevrolet	Camaro	RS
1992	Chevrolet	Camaro	RS Heritage Edition
1981-1987	Chevrolet	Camaro	Sport
1980-1987,1991-1992	Chevrolet	Camaro	Z28
1992	Chevrolet	Camaro	Z28 Heritage Edition
1982	Chevrolet	Camaro	Z28 Indianapolis 500 Pace Car
1986-1992	Chevrolet	Caprice	Base
1980-1993	Chevrolet	Caprice	Classic
1986-1990	Chevrolet	Caprice	Classic Brougham
1981-1982	Chevrolet	Caprice	Classic Estate
1980-1981	Chevrolet	Caprice	Classic Landau
1993	Chevrolet	Caprice	Classic LS
1987-1990	Chevrolet	Caprice	Classic LS Brougham
1991-1993	Chevrolet	Caprice	Classic LTZ
1980	Chevrolet	Caprice	Classic Sport
1985,1987-1989	Chevrolet	Cavalier	Base
1985	Chevrolet	Cavalier	CL
1985,1987	Chevrolet	Cavalier	CS
1986-1989	Chevrolet	Cavalier	RS
1985	Chevrolet	Cavalier	Type-10
1989	Chevrolet	Cavalier	VL
1986-1989	Chevrolet	Cavalier	Z24
1982-1989	Chevrolet	Celebrity	Base
1982-1983,1989	Chevrolet	Celebrity	CL
1985	Chevrolet	Celebrity	Classic
1982	Chevrolet	Celebrity	CS
1985-1987	Chevrolet	Celebrity	Estate
1984-1989	Chevrolet	Celebrity	Eurosport
1980-1983	Chevrolet	Citation	Base
1980	Chevrolet	Citation	Club
1980	Chevrolet	Citation	Custom
1980-1983	Chevrolet	Citation	X-11
1984-1985	Chevrolet	Citation II	Base
1984-1985	Chevrolet	Citation II	X-11
1987-1989	Chevrolet	Corsica	Base
1987-1988	Chevrolet	Corsica	LT
1989	Chevrolet	Corsica	LTZ
1988	Chevrolet	Corvette	35th Anniversary Edition
1980-1982,1984-1991	Chevrolet	Corvette	Base
1982	Chevrolet	Corvette	Collector's Edition
1986	Chevrolet	Corvette	Indianapolis 500 Pace Car
1980-1987	Chevrolet	El Camino	Base
1981-1986	Chevrolet	El Camino	Conquista
1980-1981	Chevrolet	El Camino	Royal Knight
1980-1987	Chevrolet	El Camino	SS
1983	Chevrolet	G10	Base
1980-1995	Chevrolet	G10	Beauville
1981-1984,1986-1987	Chevrolet	G10	Bonaventure
1980-1995	Chevrolet	G10	Chevy Van
1980-1995	Chevrolet	G10	Sportvan
1980-1995	Chevrolet	G20	Beauville
1983-1984	Chevrolet	G20	Bonaventure
1980-1995	Chevrolet	G20	Chevy Van
1980-1981	Chevrolet	G20	Nomad
1980-1995	Chevrolet	G20	Sportvan
1980-1996	Chevrolet	G30	Beauville
1983-1984	Chevrolet	G30	Bonaventure
1980-1996	Chevrolet	G30	Chevy Van
1980-1996	Chevrolet	G30	Hi-Cube
1980-1996	Chevrolet	G30	Sportvan
1980-1985	Chevrolet	Impala	Base
1981-1982	Chevrolet	Impala	Estate
1980	Chevrolet	Impala	Sport
1980-1981	Chevrolet	K10	Cheyenne
1981-1986	Chevrolet	K10	Custom
1980	Chevrolet	K10	Custom Deluxe
1981	Chevrolet	K10	Deluxe
1980-1986	Chevrolet	K10	Scottsdale
1980-1986	Chevrolet	K10	Silverado
1981-1986	Chevrolet	K10 Suburban	Custom
1980	Chevrolet	K10 Suburban	Custom Deluxe
1981	Chevrolet	K10 Suburban	Deluxe
1980,1982,1984-1986	Chevrolet	K10 Suburban	Scottsdale
1980,1982-1983,1985-1986	Chevrolet	K10 Suburban	Silverado
1994-1995	Chevrolet	K1500	Base
1988-1995	Chevrolet	K1500	Cheyenne
1988-1992	Chevrolet	K1500	Scottsdale
1988-1995	Chevrolet	K1500	Silverado
1991	Chevrolet	K1500	Sport
1990-1995	Chevrolet	K1500	WT
1992-1995	Chevrolet	K1500 Suburban	Base
1995	Chevrolet	K1500 Suburban	LS
1995	Chevrolet	K1500 Suburban	LT
1992-1994	Chevrolet	K1500 Suburban	Silverado
1980-1981	Chevrolet	K20	Cheyenne
1981-1986	Chevrolet	K20	Custom
1980	Chevrolet	K20	Custom Deluxe
1981	Chevrolet	K20	Deluxe
1980-1986	Chevrolet	K20	Scottsdale
1980-1983,1985-1986	Chevrolet	K20	Silverado
