OVERVIEW
- Eliminates the factory water-to-oil cooler, lowering both oil and coolant temperatures.
- Choose between Stage 1 (street/autocross) or Stage 2 (road racing) oil cooler.
- Includes ENV-135 oil thermostat in 180°F, 200°F, or 212°F.
- Professionally assembled & tested lightweight -10AN oil lines with anodized aluminum fittings.
- 100% bolt-on. No permanent modifications. Fully reversible.
- Made in USA. Lifetime warranty.
Upgrade your ND Miata's Cooling
The ND Miata uses a water-to-oil cooler from the factory, meaning your engine coolant is responsible for managing oil temperature. That works fine during a casual drive, but the moment you push the car hard, coolant temperatures climb and oil temperatures follow.
This kit replaces that system entirely with a dedicated air-to-oil cooler, so each circuit works independently.
The Result:
-
Lower oil and coolant temperatures.
-
True air-to-oil cooling performance when you need it most.
-
An engine that stays protected whether on a spirited canyon run or lap five of a hot track day.
Choose Your Driving Style
Not every Miata sees the same kind of use, so we built two options.
| Stage 1 | Uses the compact MHX-215 dual-pass oil cooler, sized for stock or lightly modified cars that see street driving, autocross, or occasional drag strip use. |
| Stage 2 | Steps up to the larger MHX-515 for drivers who road race, run extended sessions, or have added power beyond stock. If you're pushing the car hard enough to wonder whether your oil temperatures are a problem, Stage 2 gives you the headroom to stop wondering. |
| Stage 1 | Stage 2 | |
| Oil Cooler | MHX-215 (compact) | MHX-515 (larger) |
| Cooling Capacity | Up to 181 HP | Up to 410 HP |
| Best For | Street, autocross, drag strip | Road racing, modified/higher HP cars |
| Choose This If | Your Miata is stock or lightly modified | You road race, run extended sessions, or have added power beyond stock |
For most Miata owners, Stage 1 is the right call. If you're racing wheel-to-wheel or have added power beyond stock, go Stage 2.
No-Compromise Maximum Cooling
The Problem With Large Oil Coolers
An oil cooler without a thermostat cools oil all the time, including on cold starts and short trips where you actually want the engine to reach operating temperature quickly.
The No-Compromise Solution
Improved Racing's patented, high-flow ENV-135 thermostat bypasses the cooler during warm-up and only routes oil through once the target temperature is reached.
That means full cooling capacity on track, but no overcooling penalty on your morning commute. It's what makes this kit genuinely streetable year-round, not just a race-day bolt-on.
We offer three thermostat options to best match your needs.
| Thermostat | Recommended For |
| 180°F | Street and strip. Also recommended for forced induction, turbocharged, and supercharged engines. |
| 200°F | Street and strip. A great all-around choice for naturally aspirated cars. |
| 212°F | Road racing applications where high-viscosity oils are used and a higher minimum oil temperature is desired. |
Simple. Reversible. Built Right.
Everything in this kit is designed to work with existing mounting points and factory hardware for a clean, simple integration.
No drilling, no cutting, no permanent modifications, and if you ever need to return to stock, the entire install is fully reversible.
ND Miata-Specific Mounting Bracket
This isn't a universal bracket with a pile of adapters. It's engineered specifically for the ND Miata chassis to position the oil cooler where it gets clean airflow without interfering with other components.
One bracket, purpose-built, bolts right up with no fabrication and no guesswork.
Professionally Assembled Oil Lines
Every kit ships with professionally assembled and pressure-tested lightweight -10AN oil lines. They're built with a convoluted Nylon abrasion protection sleeve, weatherproof seals, and anodized aluminum dual-swivel fittings, ready to install out of the box.
No sourcing your own lines, no chasing down fittings, no wondering if your assembly will hold up at temperature.
Specifications
| Oil Cooler |
|
| Oil Cooler Port Size |
|
| Oil Lines |
|
| Oil Thermostat |
|
| Mounting Brackets |
|
| Parts Included |
|
| Country of Manufacture |
|
| Warranty |
|
Applications
- 2016-Present Mazda MX-5 Miata (ND), all trims.
| Part # |
EMA-60X
|
|---|---|
| Brand |
Improved Racing
|
| Vehicle Applications |
Mazda Miata (MX-5)
2016-Present |
| Hose Size |
-10AN
|
