PWR - 81mm Performance Intercooler (Nissan Skyline R34 GTR 99-02)

PWR manufactures the most efficient intercoolers in the world as used by the most elite motorsports categories. These charge air cooler assemblies including the core, are manufactured by hand in our state-of-the-art facilities in Indianapolis. Intercoolers are made from high grade aluminum incorporating a square nose extruded tube & fin configuration with a revolutionary louver fin design angle, which maximizes the cooling efficiencies and disbursement of heat. With these characteristics each PWR Intercooler will deliver the highest levels of quality, consistent durability, strength and performance exceeding the highest levels of customer expectation.

• Low restriction straight through integrated internal fin design
• Up to 50% lighter than competitors with thin wall extruded core
• 68mm core thickness with 77mm end plates ready to weld
• Revolutionary 16fpi fin pitch and louver angles
• State of the art controlled atmosphere brazing process
• Race and street proven performance backed by comprehensive CFD simulation & wind tunnel testing
• Pressure tested and guaranteed

Radiator Style: Crossflow
Number of Passes: Single
Inlet Location: OEM
Inlet Size: 80mm
Outlet Location: OEM
Outlet Size: 80mm
Tube Size: 81mm
